A-S701
Yamaha A-S701
€849.00
Tax included
Extremely pure sound quality and outstanding drive power.
An integrated amplifier with the advantage of digital input.
Receiver / Integrated Amplifier
| Minimum RMS Output Power (8 ohms, 20 Hz-20 kHz) | 100 W + 100 W (0.019% THD) | |
|---|---|---|
| Maximum Power (4 ohms, 1kHz, 0.7% THD, for Europe) | 160 W + 160 W | |
| High Dynamic Power/Channel (8/6/4/2 ohms) | 140/170/220/290 W | |
| Damping Factor | 240 | |
| Frequency Response | 10 Hz-100 kHz +/-1.0 dB | |
| Total Harmonic Distortion (CD to Sp Out, 20 Hz-20 kHz) | 0.019% (50 W/8 ohms) | |
| Signal-to-Noise Ratio (CD) | 99dB (input shorted, 200 mV) | |
| Audio In / Out | 8 / 2 | |
| Digital Input | Yes (optical / coaxial) | |
| Subwoofer Out | Yes | |
| DC out | Yes | |
| Pure Direct | Yes | |
| ToP-ART | Yes | |
Specifications
| Switchable CD Direct Amplification | Yes | |
|---|---|---|
Receiver / Integrated Amplifier
| Standby Power Consumption | 0.5W | |
|---|---|---|
| Power Management (Auto Power Standby) | Yes | |
| Dimensions (W x H x D) | 435 x 151 x 387 mm; 17-1/8” x 6” x 15-1/4” | |
| Weight | 11.2 kg; 24.7 lbs. | |
- Dimensions:
- 435 x 151 x 387 mm
- Weight:
- 11.2 kg
- Amplifier Type:
- INTEGRATED
- Number Of Channels:
- 2
- Power Output Per Chanell (Watt):
- 160 W
- Outputs:
- 8
- Inputs:
- 2
