MA-092
€250.00
Tax included

Wall-mounted acoustics


Frequency Response

75 Hz – 25 kHz

Nominal Impedance

6 ohms

Sensitivity (1W@1M)

85 dB

Maximum SPL

102.8 dBA

Power Handling (RMS)

50 W

Recommended Amplifier Requirements

20 – 50 W

Crossover Frequency

2.8 kHz @ 12 dB / Octave

Drive Unit Complement

2-Way
5" MMP II cone bass driver
1" C-CAM  Gold Dome tweeter

Adjustment Controls

HF Level Switch (+3 dB / 0 dB / -3 dB)

Overall Dimensions (H x W x D)

360.5 x 242 mm (143/16 x 91/2")

Overall Depth (Including Grille)

102 mm (4")

Cut-Out Dimensions

326 x 207 mm (1213/16 x 81/8")

Mounting Depth

96 mm (33/4")

Fixing Type

6 position Tri-Grip dog leg fixings

Construction Material

Mineral Filled ABS Plastic (RoHS2 Compliant)

Connection

Gold plated 'push' type terminals

Weight

2.65 kg (5 lb 14 oz)

Pre-Construction Bracket

WB6 Pre-Construction Bracket (Purple)

Sold As

Single Unit

Series:
Build-in - Controlled Performance Series
