HEAD BOX DS

Цифро-аналоговый преобразователь с усилителем для наушников

‹ ›

Цвет :

Black
Silver

355,00 €

355,00 € за gb./шт.

Количество:

• Audiophile grade headphone amp & 24bit D/A conversion

• 3 digital inputs: Asynchronous USB 2.0, S/PDIF, Toslink

• Special USB-2.0 driver for 24/192 (24/96 with USB1.1)

• Ultra low-noise semiconductors

• SMD technology for short signal paths

• Analogue output (RCA) for use as D/A converter

• Analogue input (RCA)

• Headphone socket (6,3mm jack plug)

• DC power supply (< 1 watt standby power)

• Metal case shields the electronics from vibrational and electromagnetic interference

• Faceplate silver or black

Technical specifications	Pro-Ject Head Box DS
Line-level input/output	1 pair RCA/phono sockets each
D/A-converter	Cirrus Logic CS4344, 24Bit/192kHz Delta Sigma
Supported audio format	PCM (LPCM). No support for multi channel formats like Dolby® AC-3 or DTS™
Sampling rates
USB 2.0 (MiniB) input	44,1kHz, 48kHz, 88,2kHz, 96kHz, 176,4kHz 192kHz
Coaxial input	44,1kHz, 48kHz, 88,2kHz, 96kHz, 176,4kHz 192kHz
Optical input	44,1kHz, 48kHz, 88,2kHz 96kHz
Power output	350mW/30 ohms, 60mW/300 ohms
Headphone connection	> 30 ohms
Signal-to-noise	112dB (A weighted) at full output
Frequency response	20Hz - 20kHz/-0,5dB
THD	0,0014%
Gain	9dB
Headphone jack	3-pole ¼" (6,3mm Ø)
Outboard power supply	18V/1.000mA DC suitable for your country's mains supply
Power consumption	500mA DC / < 1 watt standby
Dimensions W x H x D	103 x 72 x 144 (150) mm (D with sockets)
Weight	990g without power supply
