Songbird

TECHNICAL SPECIFICATIONS

Cartridge Type:
Moving Coil

Stylus:
0.3 x 0.7 micron Elliptical

Cantilever Material:
coated aluminum pipe

Wire Material:
pure copper

Internal Impedance:
135 Ohms

Load Impedance:
47kΩ

Frequency Response:
12Hz - 40kHz

Output Voltage:
2.5mV

Channel Separation:
30dB @ 1kHz

Channel Balance:
<0.5dB @ 1kHz

Compliance:
12x10-6 cm/dyn @ 100Hz

Recommended load capacitance:
100pF - 200pF

Vertical tracking angle:
20°

Tracking Force:
1.8g - 2.2g

Recommended Force:
2.0g

Cartridge Weight:
8.5g
