PHONO BOX USB V (DC)

PHONO BOX USB V (DC)

MM/MC Phono/line preamp with line & USB outputs

Подробнее...


Black
Silver

160,00 €

160,00 € за gb./шт.

• Preamplifier for MM or MC with switch on rear panel

• Precise RIAA equalisation

• Phono/line selector on front

• Record level adjustment

• High quality A/D conversion with USB out to PC/Mac

• Compatible with Windows®, MacOS® & Linux

• SMD technology for shortest signal paths

• Output stage with ultra-low impedance

• DC power supply (< 1 watt standby power)

• Available in black and silver

Technical data

Pro-Ject Phono Box USB V

Load capacitance / impedance MM: 47Kohms / 120pF MC: 100 ohms / 120pF
Gain, MM 40dB
Output voltage typically 300mV/1kHz at 3mV/1kHz (MM input)
Gain, MC 60dB
Gain, line level input 11dB
Max. output 9,5Vrms (1kHz)
Noise floor, MM 86dB (94dB - A weighted)
Noise floor, MC 68dB (75dB - A weighted)
THD, MM/ MC 0,01% / 0,05%
RIAA-equalisation curve accuracy 20Hz - 20kHz / max. 0,5dB
Phono Input / line output 1 pair RCA phono sockets
Line input 3,5mm jack
Output voltage 0,775Veff
A/D converter 16-Bit Delta Sigma
Sampling rate 44,1kHz
USB output digital serial data protocol USB 1.1
Operating systems Windows®, MacOS® & Linux
Standby power consumption < 1 Watt
Dimensions W x H x D 103 x 36 x 103 (109 mm with sockets)
Weight 540g
