SPECIFICATIONS
CONNECTIONS
Network
Wi-Fi 5 (802.11ac, 2.4/5GHz)
Ethernet RJ45, GigE 1000 Mbps
Audio Input
Mini TOSLINK/3.5mm Stereo combo
HDMI eARC
Audio Output
Analog Stereo RCA (Fixed or Variable)
Coaxial RCA
TOSLINK digital optical
USB Audio 2.0*
Bluetooth
Bluetooth 5.0 aptX HD
Two-Way (transmit & receive)
Headphones
3.5mm Stereo Out
Wireless Bluetooth Out
Subwoofer
RCA Out
Network Pairing to PULSE SUB+
USB
Type-A Port for external drive connection (Fat32 or NTFS formatted)
Trigger
12V Trigger Out
IR Remote
IR Sensor Built In - front panel with IR Remote Learning
IR Input 3.5mm Jack
Power
Universal bi-pin AC cord input (100-240AC)
*Note
*Available for free with future software update
AUDIO
Supported Audio File Formats
MP3, AAC, WMA, WMA-L, OGG, ALAC, OPUS
Supported Hi-Res Audio File Formats
FLAC, MQA, WAV, AIFF, MPEG-4 SLS
Processor
ARM® Cortex™ -A53, Quad-Core, 1.8GHz per core
Native Sampling Rates
up to 192 kHz
Bit Depths
16-24
Performance
SNR -113dBA
THD+N, 0.002%
DAC
32-Bit, 384kHz
Differential Output design
SOFTWARE & INTEGRATIONS
Operating System
BluOS
App Controller Operating Systems
iOS, Android, Windows Vista, 7, 8, 10, macOS 10-11
Network File Sharing
SMB up to 200,000 track index
Album Art Supported
JPG, PNG
Internet Radio
Click here
Music Services
Click here
Voice Control
Amazon Alexa Skills; Actions on Google
3rd-Party
AirPlay 2
Spotify Connect
Tidal Connect
Roon Ready
Control Systems
Control4, Crestron, URC, RTI, ELAN, Lutron
USER INTERFACE & CONTROLS
Status Indicator
RGB LED x 2
Play/Pause Button
Touch LED
Volume Control Buttons
Touch Slider LED
Previous/Next Track Buttons
Touch LED
Preset Buttons
Touch LED x 5
Proximity Sensor
Yes
GENERAL
Finish
Black/White; Matte Satin Paint
Included Accessories
120V AC Power Cord
230V AC Power Cord
Ethernet Cable
Stereo RCA to RCA Cable
TOSLINK Optical to 3.5mm Mini Adaptor
Safety/Warranty Guide
Quick Setup Guide
Power Consumption
Storage Environment
-10°C to 50°C, 20% to 80% relative humidity
Operating Environment
0°C to 40°C
Product Weight
1.09kg/2.4lbs
Product Dimensions
220 x 46 x 146 mm
8.7 x 1.8 x 5.7 in
Shipping Weight
2.28kg/5.03lbs
Shipping Dimensions
300 x 300 x 74 mm
11.8 x 11.8 x 2.75 in
