MC8207

POWER OUTPUT PER CHANNEL

200W @ 4 or 8 Ohms

NUMBER OF CHANNELS

7 (can also be used as a 2-zone amplifier with 5 channels in zone A and 2 channels in zone B)

TOTAL HARMONIC DISTORTION

0.005%

S/N BELOW RATED OUTPUT

112dB

DYNAMIC HEADROOM

1.7dB

REMOTE POWER CONTROL

Yes, 7 or 5 + 2 Channel

CIRCUIT CONFIGURATION

Push-Pull Complementary

CIRCUIT DESIGN

Transistor

MONO BRIDGE

No

MONO PARALLEL

No

AUTOFORMER

No

METERS

Yes, new style LED

DIMENSIONS (W X H X D)

17-1/2" (44.5cm) x 9-7/16" (23.9cm) (including feet) x 21" (53.3cm) (including front panel and cables)

WEIGHT

83 lbs (37.6 kg)
