MC152

Write your review

Stero pastiprinātājs

150 Watt per channel

Sīkāk...

‹ ›

Redzēt visus attēlus

Ref.: mc152

Vairāk info
Datu lapas

ELECTRONIC SPECIFICATIONS

POWER OUTPUT PER CHANNEL

150W @ 2, 4 or 8 Ohms

NUMBER OF CHANNELS

TOTAL HARMONIC DISTORTION

0.005%

S/N BELOW RATED OUTPUT

118dB Balanced
115dB Unbalanced

DYNAMIC HEADROOM

2.0dB

DAMPING FACTOR

>40 Wideband

RATED POWER BAND

20Hz to 20kHz

FREQUENCY RESPONSE

+0, -0.25dB from 20Hz to 20,000Hz
+0, -3.0dB from 10Hz to 100,000Hz

CONTROL

REMOTE POWER CONTROL

Yes

MULTI CHANNEL DB25 CABLE

GENERAL SPECIFICATIONS

CIRCUIT CONFIGURATION

Push-Pull Complementary

CIRCUIT DESIGN

Transistor

MONO BRIDGE

MONO PARALLEL

AUTOFORMER

Yes

METERS

Yes

METER LIGHT SWITCH

Yes

BALANCED INPUT

1 Stereo

FRONT PANEL

Glass

ILLUMINATION

LED Fiber Optic

CHASSIS STYLE

Enclosed Steel

GOLD PLATED BINDING POSTS

Yes, New Style McIntosh

WEIGHTS & DIMENSIONS

DIMENSIONS (W X H X D)

17-1/2" (44.45cm) x 6" (15.24cm) (including feet) x 21" (50.8cm) (including front panel and cables)

WEIGHT

75 lbs (34 kg)

SHIPPING WEIGHT

85 lbs (38.6 kg)

Izmēri: 17-1/2" (44.45cm) x 6" (15.24cm) (including feet) x 21" (50.8cm) (including front panel and cables)
Svars: 85 lbs (38.6 kg)
Pastiprinātāja tips: Izbeigšana
Būves shēma: Tranzistors
Kanālu skaitlis: 2
Pretestība: 2, 4 or 8 Ohms
Jauda katram kanālam (Watt): 150 W
