PHONO BOX RS

Highend phono preamplifier

Sīkāk...

‹ ›

• MM & MC capable

• True dual mono design

• Balanced XLR & unbalanced RCA In & Outputs

• Fully passive RIAA & DECCA equalisation

• Unique continously variable input impedance loading,

matches every cartridge (adjustment even while playing)

• RCA & XLR In & Out

• Superior low noise / low distortion

• Classy & elegant dip switches

• DC power supply (< 1 watt standby power)

• Metal casing protects against vibration and interference

• Faceplate silver or black

Technical data	Pro-Ject Phono Box RS
Input impedance	Fixed 10 ohms or 47kohms,
	variable 10 - 1200 ohms
Load capacity switchable	100pF 200pF, 300pF, 420pF, 520pF
Output impedance	50 ohms
Gain, MM / MC	RCA: 40, 50, 60 dB
	XLR: 46, 56, 66 dB
Signal to noise ratio	80dB (91dB - IEC -A)
THD	< 0,019%
RIAA accuracy	within 0,3dB/20Hz - 20kHz
SubsonIc	20Hz / - 12dB
Input	RCA & XLR
Output	RCA & XLR
Power supply	+2x 18V/300mA DC; 220 - 240V, 50Hz
Power consumption	150mA DC < 1 watt standby
dimensions W x H x D (T with sockets)	206 x 72 x 200 (210)mm
weight	2000g without power supply
