DAC BOX TV

Digital to analogue converter

Sīkāk...

Ref.: PROJECT-776

• Audio-upgrade for TV, Sat, Computer ...

• 24bit/192kHz Cirrus Logic DAC chip

• Supports 24bit audio data

• Up to 192kHz sampling rates

• Automatic signal sensing technology

• Low clock jitter sensitivity

• RCA connectors gold plated (in & out)

• Metal casing protects against vibration and interference

• Black casing only

Technical data	Pro-Ject DAC Box TV
D/A-converter	Cirrus Logic CS4344 (Delta-Sigma type)
Sampling rates (coax)	32/44,1/48/88,2/96 kHz,
Sampling rates (optical)	32/44,1/48/88,2/96 kHz
Digital inputs	1 x coax (S/PDIF)
	1 x optical (Toslink®)
Dynamic range	105dB
Analogue out	1 pair RCA/Cinch
Output voltage	0,7 Veff
Output impedance	< 100 ohms
THD	-90dB
Power consumption	< 1 watt standby, 200mA max
Power supply	5V/1000mA DC; 220 - 240V, 50Hz
Dimensions W x H x D	107 x 30 x 64 (75) mm (incl. sockets)
Weight	290g without power supply
