CAT 8 STP PATCH FRHF BLUE

Supra Cat 8 Network Cable - Astonishing speed and accuracy!

Supra Cat 8 is once more one step ahead by providing a future proof cable, e.g. 40GBASE-T over one singel cable! It is used beneficially in TCP/IP and UDP applications where bit-correct, jitter-free data transmissions is critical, e.g. 4K and 8K video streaming, high quality music streaming (e.g. 32 bits @ < 700 kHz for some downloadable music and in-studio applications), gaming and data centers, and in-building installations such as hotels, conference facilities, among others.

Further it is available pre-connected as patch cables in a number of standard lengths, refer to available variant meny, pre-connected with Supra RJ45 Connectors, a fully shielded connector supporting the astonishing performance of the cable also under tough service conditions and it is possible to connect on-site.

HDBaseT is transmitted over 6A up to 100 m (328 ft) long, with 8P8C modular connectors of the type commonly used for ethernet local area network connections. From Cat 6A to Cat 8 the step is four times the bandwidth. Supra Cat 8 allows for 2,000 MHz(!) an incredible transfer speed providing for quality enhancing massive headroom.

HDBaseT transmits uncompressed ultra-high-definition video (up to 4K), audio, power over HDBaseT (PoHDBaseT - up to 100W), Ethernet, USB, and a series of controls such as RS and IR.

Features and benefits

• Performance better than "8.2" according to preliminary specification IEC 61156-10 - Astonishing future proof transfer speeds
• Excellent NEXT (= crosstalk), very low dampening and mutual lead pair interference - Bit correct transfers
• Low dampening - Long cable lengths without signal degradation or voltage drops for PoE
• Excellent shielding, both pair and total - Almost completely interference immune with very low pick-up
• Low jitter, perfect timing - Very low bit stream timing errors gives low needs for error corrections, thus high transfer speeds
• Bandwidth at 2,000 MHz - Buckle up because this is going to be a ride to remember ...
• Flame retardant, halogen-free - Allowed in public spaces and buildings
• Made in Sweden!

Usage

Installation and patch cable for all networks conforming to ISO/IEC 11801 and EN 50173 (2nd issue), for computer centrals according to ISO/IEC 24764, EN 50173-5 and also TR 11801-99-1. Ideal for all applications from D up to FA and Class II, Multimedia (TV, video, data, voice) >40 GbE enligt IEEE 802.3 bq (draft), cabel sharing, VoIP and PoE/PoE+.

Mechanical Specifications

Cable design

Electrical performance
